KOVAK

The World's First Tilt-Motor Vtol Attack UAV

Kovak IHA does not need a catapult and becomes ready for flight in maximum 3 minutes. Thanks to the built-in artificial intelligence, it reaches its target autonomously.  It can drop its payload on the target or perform its mission by hitting the target directly

45 Minute

Maximum Flight Endurence

2000 Meters

Operation Celling

1.5 Kg

Maximum Payload Weight

8 Kg

Maximum Take-Off Weight

45 Km

Communication Range

Day/Night

Flight

Propulsion

Electric Engine & Li-Po Battery

45 Km

Maximum Range

Model Overview

  • Take-Off Weight

    8 kilogram

  • Max. Flight Time

    45 Minutes

  • Command and Control Range

    45 km

  • Cruise Speed

    120 km/h

  • Wind Tolerance (ground)

    10 m/s

  • Operational Flight Altitude

    From 5 meters (above ground level) up to 4500 meters (above sea level)

  • Wingspan

    160 cm

  • Fuselage Length

    120 cm

Flight Control and Attack Systems

apps

Various Flight Modes

Flight on a predefined route. Change of course during flight (if radio communication is available.) Flight to a specific location according to global navigation coordinates. Circling around a defined area. Real-time video streaming, video recording and playback. Flight capability using swarm technology.

Attack Method

The operator launches an attack on the selected target. During the execution of the attack, the flight control of the KOVAK is semi-automatic. The user is presented with a real-time video stream of the attack on the ground control station monitor. The operator can select multiple attack angles and determine the point of detonation of the munition. Remote Mission Termination after Kovak stay (if radio communication is available) Patented function for remote attack cancellation with the possibility of returning or re-attacking the target.

Distance Sensors

LIDAR and optical sensors are used. It can fly day and night. Remote Self-Destruction of KOVAK (if radio communication is available) The warhead can be detonated in flight and can destroy all structural elements of the KOVAK

Control Panel

Intuitively understandable, safe, compact tablet combining flight and fire control unit (F&CU)

Sensor Options

Full HD 1080, 1/2.9, IR Thermal Imager, EO/IR Camera Object Tracker, IR Laser Rangefinder

Ammunition options

All ammunition in the inventory weighing up to 2 kg can be integrated. Thanks to this feature, ammunition procurement is no longer a problem.

Common Attributes

  • Ease of deployment and use of the combat system

  • Thermal and RF systems

  • Compact design

  • Low thermal, radar and acoustic visibility

  • Less than 3 minutes setup time

  • A “vtol lift” can be performed by a physically trained person.

  • It can be carried by one person in a backpack and is ready to work with quick setup

Break boundaries with UAVs! Contact us for more information.
